This Alabama pool plan is based on a Les Paul guitar shape. The owner is a musician and wants the pool to be shaped by their interest. The spa is an infinity spillway into a trough the forms the neck and fretboard that travels into the main body of the pool. The main pool features a vanishing edge in a small portion to accent the shape. There is a shallow area dedicated for the young children to play that helps keep them from entering the main pool. You would be hard pressed to find another pool plan in Alabama that is as interesting as this one; it even has a planter bed for the guitar pick.
Pool Design Details
Pool Type: Gunite
Pool Style: Guitar shape
Spa: Yes, raised 16″
Spa Height: Infinity Spa spillway
Spa Spillway: Spillway on all sides, minimal
Pool Length: 52′
Pool Width: 15′
Pool Wall: None
Depth Profile: Gradual slope to deep end
Min Pool Depth: 3.5′
Max Pool Depth: 6′
Perimeter: 175′
Surface area: 701 sqft
Capacity: 18,000 gallons
Decking max sqft: 2,500 sqft
How many lights: 8
Sun ledge: Yes, large within the neck/fretboard area
Other Water features: Cascade bubblers
Brand of equipment: Pentair
Type of sanitation: Chlorine, Salt System
Include heater: Yes
Design Materials
Waterline tiles: 1×1 Glass Mosaic pool tile, 12×12 marble galaxy or black color
Interior surface: Pebble with glass bead
Coping material: Natural Stone, square edge
Decking material: Concrete, Salt Finish
Vertical Faces materials: Ledge Stone, Split Face, Stucco
