Swimming pool site drainage plan drawing showing measurements and callouts detailed as it pertains to the requirements of your building department.

If you require a drainage plan for adding a pool this needs to be added to your pool construction plans order. Not all building departments require drainage plan drawings for submitting and that is why this is a separate service we offer if you need it. Please check with your building department to see if this is required or if you would just like to have it anyway. This can include up to 2 sheets showing typical detail, drain lines, downspouts, overflow, run-off direction callouts, and runs.

Must be purchased with or previously purchased a pool construction plan set. If you have already purchased a construction plan set we can invoice you separately for the cost of this plan.

ATTENTION

Not included with a standard set of construction sheets.
*This cost can vary depending on the overall complexity of the design.
Must be purchased with or previously purchased a pool construction plan set.
